Warrior Winches Elite Combat 10000 lbs. Capacity Winch with Synthetic Rope Warrior Winches Model: T1000-100AE
price for vip customer
$1,199.99

OR PAY WITH

Product Features & specs :

Warrior Winches Elite Combat 10000 lbs. Capacity Winch with Synthetic Rope

Details

Built specifically for military use, able to withstand extreme climates and temps. Features include hardened 3 stage planetary gears for reliable and efficient use in the harshest environments. The waterproof remote control has thermometric LED indicators signals to monitor the temperature of the motor and high temp lithium grease is used which doesn't solidify in extreme climates.

Features:

  • IP68 Rated Military Grade Winch and Control Box

  • Hardened 3-Stage planetary gears

  • Waterproof remote control with LED indicators

  • Corrosion and Chemical Resistant Powder Coat

  • High Temperature Lithium Grease that won't solidify in extreme temperatures

  • Rated Line Pull: 10000 lbs. (4536 kg.); Motor at 12V: 4.6kW / 6.2 HP, at 24V: 6.5kW / 8.7HP; Gearing 228:1; Drum Size - Dia x L: 63 mm x 217 mm (2.48 in. x 8.5 in.); Cable - Dia x L: 9.1 mm x 25 m (0.35 in. x 82 ft.); Dimensions: 574 mm x 16 mm x 259 mm (22.6 in. x 6.3 in. x 10.2 in.); Mounting Pattern: 254 mm x 114.3 mm (10 in. x 4.5 in.) 4-M10; Weight (kg) 37.5 kg. (82.7 lbs.)

  • Layer of Rope/Cable, Line Pull: lbs. (kg.), Rope on drum ft. (m): 1, 10000 (4536), 16.1 (4.9); 2, 7980 (3620), 36.4 (11.1); 3, 6640 (3012), 61 (18.6); 4, 5680 (2576), 82 (25)

  • Line Pull (lbs. / kg.), Line Speed 12V ft./min (m/min.), Line Speed 24V ft./min (m/min.), Amp Draw at 12V, Amp Draw at 24V: 0, 32.2 (9.8), 34.4 (10.5), 65, 45; 3000 (1361), 14.8 (4.5), 16.4 (5), 140, 85; 6000 (2722), 10.5 (3.2), 12.5 (3.8), 260, 140; 8000 (3629), 7.5 (2.3), 9.8 (3), 320, 175; 10000 (4536), 5.2 (1.6), 7.5 (2.3), 380, 210

  • Note: Slight color variations may occur from images shown

What’s Included:

  • Elite Combat 10000 lbs. Capacity Winch with Synthetic Rope - T1000-100AE

Capacity

10000 lbs

Construction

Steel

Cable Length

25 m

Weight Capacity

10000 lbs

Horsepower

6.2 / 8.7

Voltage

12V / 24V

Cable Diameter

9.1 mm

Length

24.1 in.

Width

6.3 in.

Height

10.2 in.

Weight

82.6 lbs.

Warranty Term

1 Year
